Model No.︰C1100
Brand Name︰CANHU/OEM
Country of Origin︰China
Unit Price︰US $ 10 / KG
Minimum Order︰100 KG
| Item | Unit | Thickness | ||||||
| 9um | 12um | 18um | 35um | 70um | 90um | |||
| Mass Per Unit | g/m2 | 80.1±4.45 | 106.8±8.9 | 160.2±8.9 | 311.5±17.8 | 623±17.8 | 801±17.8 | |
| Purity | Cu | % | ≥99.97 | |||||
| Surface Roughness | Ra | um | ≤0.2 | |||||
| Tensile Strength | Rm(Hard) | N/mm2 | 420-440 | 450-470 | 460-480 | 430-450 | 410-430 | |
| Rm(soft) | N/mm2 | 160-180 | 180-220 | 200-230 | 210-240 | 220-250 | ||
| Elongation | A50(Hard) | % | 0.8-1.2 | 0.8-1.3 | 1.0-1.5 | 1.2-1.8 | 1.5-2.0 | |
| A50(Soft) | % | ≥5.0 | ≥6.0 | ≥8.0 | ≥10.0 | ≥15.0 | ≥20.0 | |
| Oxidation Resistance | 200℃ | Min | 60 | |||||
| PINHOLE | EA | NONE | ||||||
| WIDTH | mm | 100-660 | ||||||
| Width Accuracy | mm | 0~ +2 | ||||||
| Core | / | 3 in, 6 in, 80mm | ||||||
Payment Terms︰ T/T, L/C
